Water Cooling Xenon-Arc Lamp Exposure Environmental Test Chamber
Complied Standards & Clauses
SAE J2412: "(R) Accelerated Exposure of Automotive Interior Trim
Components Using a Controlled Irradiance Xenon-Arc Apparatus"
SAE J1545: "(R) Instrumental Color Difference Measurement for
Exterior Finishes, Textiles and Colored Trim"
IEC60068-2-5 “Environmental testing -Part 2-5: Tests-Test Sa:
Simulated solar radiation at ground level and guidance for solar
radiation testing, IDT”
AATCCM16 “Colorfastness to Light: Xenon-Arc”
ASTM-D4459 “Standard Practice for Xenon-Arc Exposure of Plastic
Intended for Indoor Applications ”
GB/T16422.3 -2014 / ISO 4892-3:2006 “Plastics-Methods of exposure
to laboratory light sources-Part 3: Fluorescent UV lamps”
Equipment Overview
The aging test is carried out by exposing the material of the
samples (which including but not limited to automotive, coatings,
rubber, plastics, pigments, adhesives, fabrics, aerospace,
shipbuilding, electronics, packaging, etc.) to the illumination and
heat radiation of the xenon arc lamp, to evaluate the light and
weather resistance of some materials under the action of high
temperature light source.
Xenon arc lamps simulate full sunlight spectrum to reproduce
destructive light waves in different environments.
Technical Parameters
| Model | SN883- X65 |
| Dimensions | 124cm×114cm×202cm (W×D×H) |
| Exposure area | 6500cm2/ About 65 standard samples (140mm×70mm) |
| Light source | 6.5kW long arc water-cooled xenon lamp (imported from the United
States Q-LAB) |
| Light source life | About 2000h (based on irradiance 0.51W/m2 @340nm) |
| Irradiance display band | 340nm, 420nm, 300～400nm optional |
| Irradiance range | 0.3W/m2～1.1 W/m2(@340nm) 40 W/m2～120 W/m2(@300nm～400nm) |
| Sample temperature | Blackboard temperature: 40℃～110℃ Black mark temperature:40℃～120℃ |
| Temperature in the chamber | 38℃～80℃ |
| Humidity in the chamber | When illuminated: 30%RH～75%RH (related to temperature) In the dark: up to 100%RH |
| Test Conditions | Free combination of light, darkness and water spray Note: the water spray can be performed or not, if water spray is
not used as per IEC 62368-1 Annex C.2.4, operator can set the spray
time to be “0”. |
| Supported test standards | Conforms to SAE J2412, SAE J2527, ASTMG 155ISO 105-B02, ISO
105-B04, ISO 105-B06, ISO 4892-2-A, ISO 11341-1, GB/T 16422-2, GB/T 1865
With 4 custom methods, users can set test parameters by themselves
to meet most common standard requirements. |
| Drum sample holder |
The rotating drum sample holder can ensure the excellent irradiance
uniformity of the upper, middle, and lower samples while taking
into account the sample volume. In addition, the sample
continuously rotates around the lamp tube with the sample holder to
further ensure uniform and stable irradiance, sample surface
temperature, and water spray. |
| Control system |
| HMI | Comprehensive and easy-to-use human-machine interface (Will be in
English)
|
| Main controller | Adopting the American GE company PLC, the control is accurate,
stable and reliable. |
| Data logging and export | Automatic recording of equipment operating status and various test
parameters, users can export data for a specified period of time as
needed. |
| Safety protection function |
Overcurrent protection
Over high and low irradiance alarm protection
Over temperature protection Cooling water high temperature protection Low cooling water flow alarm protection
Low cooling water level alarm protection
Fan failure alarm protection
Door open alarm protection |
| Use conditions |
| Power source | AC 380V, 60Hz, three-phase five-wire (including ground wire) |
| Water source | Tap water: 0.14～0.3 MPa
Laboratory secondary water: 0.08～0.15 MPa
Laboratory secondary water consumption: about 150 L/day |
| Drain | The height of the drain from the ground: ≤15cm
Drain interface diameter: ≥5cm |
| Ambient temperature | 18℃～28℃ |
| Environment humidity | 10%RH～85%RH |
| Installation space | ≥280cm×300cm×280cm (W×D×H) |
| Environmental conditions | Indoor, clean, less dust, flat ground, there is no corrosive,
flammable, explosive gas, liquid, dust around |
Questions & Answers
Q: What about the exposure area?
A:6500cm2/ About 65 standard samples (140mm×70mm)
Q: What is the Radiation Intensity of Xenon?
A:0.3 W/m2～1.1 W/m2(@340nm)
40 W/m2～120 W/m2(@300nm～400nm)
SN883-X65 can reach 2 of levels which close to the sun level .
Other domestic equipment is generally customized based on a certain
standard and does not understand the irradiance requirements of
different fields.
Q: What's the cooling system?
A:SN883-X65 can reach a higher power level to meet the needs of
current and future test development. There is cooling water flowing
between the filters, which can effectively reduce the infrared heat
to the sample surface. And reduce the generation of ozone, increase
the accurate matching with the external environment.
Cooling effect remark: water cooling is better than air cooling.
