    Industrial Van Shower Test System Commercial Vehicle Rain Test Waterproof System

    Ask Lasest Price
    Brand Name : Sinuo
    Model Number : SNQC1001
    Certification : Calibration Certificate (Cost Additional)
    Price : Customized
    Payment Terms : T/T
    Supply Ability : 5 Sets Per Month
    Delivery Time : 60 Days
    • Product Details
    • Company Profile

    Industrial Van Shower Test System Commercial Vehicle Rain Test Waterproof System


    Industrial Van Shower Test System Commercial Vehicle Rain Test Waterproof System


    Complied Standards & Clauses



    Conforms to IEC 60529 Degrees of protection provided by enclosures (IP Code);

    Product Overview



    Our Commercial Vehicle Rain & Waterproof Performance Test System is designed to simulate natural rain environments and evaluate the rainproof sealing of vehicles in full accordance with IEC 60529, QC/T 476-2007, GB 29753-2013, and related national standards.

    This comprehensive rain test and drying system helps automakers and commercial vehicle manufacturers verify the waterproof sealing of windows, doors, skylights, and enclosures—critical for refrigerated trucks, insulated vans, and passenger vehicles. With precise spray angles, pressure control, flow rate regulation, and drying functionality, this system ensures that no leakage, fogging, or water-induced damage affects your product quality or safety certification.

    Built with intelligent PLC controls, reliable filtration systems, and energy-efficient drying, it’s a one-stop solution for factory inspection, R&D validation, and technical compliance—keeping your production line safe, compliant, and efficient.


    Technical Parameters



    Item

    Specification

    Standards ComplianceIEC 60529, QC/T 476-2007, GB 29753-2013, QC/T 450-2010, QC/T 453-2009
    Test ObjectCommercial vehicles (vans, refrigerated trucks, etc.)
    Rain Intensity5–12 mm/min (±1 mm/min)
    Spray Angle45° to vertical
    Test Duration30 minutes
    Spray Pressure69–150 kPa (±10 kPa)
    Nozzle Diameter2.5 mm (±0.01 mm)
    Nozzle Spacing400 mm (horizontal and vertical)
    Distance from Vehicle Body700 mm ±200 mm
    Water Pump ModelKQL100/220-30 (Shanghai Kaiquan)
    Pump Flow / Head / Power100 m³/h, 40 m, 30 kW (x2 units: 1 active, 1 backup)
    Sewage Pump ModelQDX15-10-0.75
    Sewage Pump Flow / Head / Power45 m³/h, 8–13 m, 3.0 kW
    Power SupplyAC 380V, 3-phase, 50Hz
    Control SystemPLC + control panel + remote control
    Drying MethodCool air drying via top and side-mounted stainless steel fans
    Drying Air Outlet HeightMax: 2800 mm; Side ≥ 2600 mm
    Noise Level (at 1m)≤ 75 dB
    Structure MaterialHot-dip galvanized steel + EPS sandwich panel (50 mm thick)
    Filtration SystemTriple-stage sedimentation + 304 stainless-steel mesh filter
    Room SizeDesigned for 14m vehicle; drive-in / drive-out configuration
    Maintenance AccessPedestrian door + ladders + lighting for top fan area

    Details



    Industrial Van Shower Test System Commercial Vehicle Rain Test Waterproof SystemIndustrial Van Shower Test System Commercial Vehicle Rain Test Waterproof System
