    ISO 16750-3 Commercial Vehicle Engine Acceleration Shock Test System

    Ask Lasest Price
    Brand Name : Sinuo
    Model Number : SN558-HSKT50
    Certification : Calibration Certificate (Cost Additional)
    Payment Terms : T/T
    Supply Ability : 10 Sets Per Month
    Delivery Time : 30 Days
    • Product Details
    • Company Profile

    ISO 16750-3 Commercial Vehicle Engine Acceleration Shock Test System


    ISO 16750-3 Commercial Vehicle Engine Acceleration Shock Test System


    Complied Standards & Clauses



    Conforms to MIL-STD-202F, IEC-68-2-27, MIL-STD-810F, MIL-STD-883E, ISO 16750-3, etc.


    Product Overview



    Mechanical shock testing machine is mainly suitable for shock resistance tests in the fields of electronic products, aerospace, shipbuilding, military industry, automotive parts, transportation, etc. By selecting different waveform generators, half-sine wave, post-peak sawtooth wave or square wave shock tests can be performed.

    The equipment meets the test specifications of MIL-STD-202F, IEC-68-2-27, MIL-STD-810F, MIL-STD-883E, ISO 16750-3, etc.


    Technical Parameters



    Impact machine main parameters
    Work Platform500×600 mm
    Maximum load50KG
    Peak accelerationHalf sine wave 10--- 600G
    Pulse durationHalf sine: 2-30 ms
    Acceleration tolerance≤10%
    Speed ​​change≤10%
    Horizontal ratio of table≤10%
    Device size1230×1120×2330mm
    Total equipmentAbout 1750 kg
    Measurement system
    Input Channels2 channels
    Sampling frequency192KHz
    Pulse duration0.5—100ms
    Maximum acceleration5000G
    Communication interfaceUSB2.0
    Supported standardsISO,MIL-STD-810, or user defined
    Operating systemMicrosoft Win7/10
    System Accelerometer
    ModelC02A01
    Output methodCharge Type
    Sensitivity3.93pC/g
    Frequency range0.5---12KHz
    Acceleration range±2500G
    Work Environment-40~+160℃
    Other notes
    Power supplyAC3 phase 380V±10%5KVA
    Compressed air0.5-0.8Mpa
    TemperatureRT~40℃
    Humidity25℃<85RH%
    Reliability

    Average failure-free rate ≥ 5000 hours;

    The half-sine waveform generator is used continuously for no less than 8000 times;

    The storage time in a clean, normal temperature environment is no less than 5 years

    Applicable standardsIEC68-2-27, MIL—STD202F,MIL-STD810B, ISO 16750-3, etc.

    Details



    ISO 16750-3 Commercial Vehicle Engine Acceleration Shock Test SystemISO 16750-3 Commercial Vehicle Engine Acceleration Shock Test System
